WN Carbon Steel Forged Steel Flanges A105 150LB 300LB 600LB
Contact Person : John Lee
Phone Number : +86-13663270486
WhatsApp : +8613663270486
| Minimum Order Quantity : | 1 piece | Price : | 0.15 |
|---|---|---|---|
| Packaging Details : | Wooden box Wooden pallet | Delivery Time : | 10 Work Days |
| Payment Terms : | L/C, T/T, D/P | Supply Ability : | 100000 |
| Place of Origin: | CHINA | Brand Name: | Yi Sheng |
|---|---|---|---|
| Certification: | ISO 9001 BV | Model Number: | 1/2"-76" |
|
Detail Information |
|||
| Color: | Yellow Oil /Black | Name: | WN Flange |
|---|---|---|---|
| Standard: | ANSI,DIN,JIS,BS,ASME | Surface: | Sand Blasting Black Oil Yellow Oil |
| Type: | Blind,weld Neck Flange SO | Technics: | Forged |
| Size: | 8" | Material: | Carbon Steel |
| Certification: | ISO BV | Port: | Tianjin |
| High Light: | P235gh Forged Steel Flanges,A105 Forged Steel Flanges,P250gh Carbon Steel Pipe Flange |
||
Product Description
A105 P235gh Forged Steel Flanges P250gh Carbon Steel Pipe Flange
Hebei Yisheng piping is specializes in manufacturing & exporting carbon steel pipe fittings and flanges. The professional manufacturing capacity of FITTINGS strongly guarantees the high quality, competitive price and short delivery time,has have accumulated rich experience and good reputation in years of serving customers, which making us a reliable pipe fittings & flange supplier to clients from countries over the world.
Products Description:
| Carbon Steel Pipe Flange Weld Neck Blind 150 | |
| Type | Forged Threaded Pipe Fittings(NPT/BSPT/BSP), Forged Socket Welded Pipe Fittings |
| Specification | Elbow, Cross, Street Elbow, Tee, Coupling, Half Coupling, Reducing Coupling |
| Outlet, Cap, Bushing, Union, Hex Nipple, Hex Plug, Square Plug, Round Plug, Boss | |
| Size | 1/8"---72" |
| Pressure Rating | Threaded Fitting: 2000LB/3000LB/6000LB(Sch40, Sch80, Sch160) |
| Socket Welding: 3000LB/ 6000LB/9000LB(Sch80, Sch160, XXS ) | |
| Carbon Steel: ASTM A105N, A350 LF2, A350 LF3 | |
| Material | Stainless Steel: |
| ASTM A182 F304, F304L,F316, F316L, F321, F347, F310, F43, F44, F51 | |
| A276 S31803, S32750, A705 631, 632, A961, A484. | |
| Alloy Steel: | |
| ASTM A694 F42, F46, F52, F56, F60, F65, F70 | |
| A182 F12, F11, F22, F5, F9, F91, F1, etc. | |
| Standard | ASME/ANSI B16.11, B 1.20.1, MSS SP-79/83/95/97, JIS, B2316, GB/T 14626 etc. |
| Surface | Varnished, Galvanized, as per customer’s requirements. |
| Connection | Threaded(NPT/BSPT/BSP), Socket welded |
| Shape | Equal, Reducing |
| Applications | Petroleum, Gas, Power, Chemistry, Metallurgy, Shipbuilding, Urban Construction etc. |
| Type | Forged |
| size | 1/2"-72"(DN15-DN1200) |
| connection | welding |
| technic | forged |
| varieties | SCH20, SGP, STD, SCH40, SCH80, SCH160 |
| material | carbon steel ,stainless steel WPBA234,Q235,20#,A420 A403-WP304,A403-WP316,A403-WP316L,A403-WP317,A403-WP321 etc. |
| standard | BS, DIN ,JIS,etc. ANSI B16.9/16.28, ASTM,API 5L, DIN2605/2615/2616, JIS P2311/2312 ASME B36.10M---1996 |
| connection | welding |
| quality | first grade |
| Certification | ISO9001 - 2000, CE, SGS, etc. |
| Application | petroleum, electricity, chemicals, natural gas, construction, shipbuilding and other fields because of its high pressure, high temperature, etc |
| Packaging | wooden case,pallet ,container or in accordance with the requirements of customers |
| principle | quality first,customer first,credit first, |
| payment | L/C T/T D/P... |
| Surface treatment | Black rust-proof oil, transparent oil, hot galvanizing |
| notes | The bevel can be made according to the special requirements of the customers |
| others | we can also produce the products accordance with the requirements of customers |
| Material |
Carbon Steel |
|
| British Standard | Threads :ISO 7/1 | |
| Dimension: BS EN 10242, BS 143&1256 | ||
| Chemical property | (C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S% <0.2%) | |
| Physical property | Tensile strength >=300MPa, Elongation >=6%, Hardness <=150HB | |
| Testing pressure | 2.5MPa, 100% test before shipment | |
| Working pressure | 1.6MPa | |
| Type | Banded without ribs, Beaded with ribs. | |
| Size | 1/8",3/8",1/2",3/4",1",11/4",11/2",2",21/2",3",4",5",6". | |
| Surface | Ø Galvanized | |
| Ø Normal black/Shining black | ||
| Series | Heavy, Standard, Medium, Light | |
| Model | Elbows, Tees, Crosses, Bends, Unions, Bushings, Lateral Y Branches, Sockets, Nipples, Hexagon/Round Caps, Plugs, Lock nuts, Flanges, Side Outlet Tees, Side Outlet Elbows, etc. |
|
| Related products | 1. Carbon steel nipples and sockets | 2. Flanges |
| 3. Carbon steel butt-welding fittings | 4. Pipes | |
| 5. High-pressure fittings | 6. Valves | |
| 7. P.T.F.E .thread seal tape | 8. Brass fittings | |
| 9. Ductile iron pipe fittings | 10. Copper fittings | |
| 11. Grooved fittings | 12. Sanitary fittings, etc. | |
| Connection | Male, Female | |
| Shape | Equal, Reducing | |
| Applications | Suitable for Pipe lines connect of water, steam, air, gas, oil and so on. | |
| Buyer's drawings or designs are available. | ||
| Package | 1. Cartons without pallets. | |
| 2. Cartons with pallets. | ||
| 3. Double woven bags | ||
| Or as buyer's requirements. | ||
| Delivery detail | ||
| According to the quantities and specifications of each order. | ||
| Normal delivery time is from 30 to 45 days after receiving the deposit. | ||
Products Pictures:
Packaging&Transportation :
Company Profile :
HEBEI YISHENG PIPING CO., LTD. was founded in 1998 and located in the hometown of martial art ----Cangzhou city,China. Our factory is set up in Zhangguandian Industrial Area,Mengcun County. The traffic is very convinient around our factory.
Our company mainly produce piping equipments including stainless, carbon and alloy steel pipe fittings which are used in oil project ,chemical industry and so on. We have many lines for producing elbows, Tees, educers,caps and flanges. With the most efficient machines and the advanced testing machines, we can produce varies kinds of pipe fittings for you.With it's standards covers from Japanese, American and Germany standard . In order to establish good reputation around the world's market, we will strengthen our management and improve our service continuously.
We welcome you to visit our factory in the near future and hope we can start a good relationship very soon.
FAQ
1. Are you trading company or manufacturer?
We are manufacturer .
2. How long is your delivery time?
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
3. Do you provide samples? Is it free or extra?
Yes, we could offer the sample for free charge but need pay the cost of freight.
4. What is your terms of payment
Payment<=1000usd, in="" advance.="" payment="">=1000USD, 30% T/T in advance ,balance before shippment.
